Fayl:Radio Fix on 2 Stations.svg
Size of this PNG preview of this SVG file: 600 × 475 piksel. Boshqa oʻlchamlari: 2 560 × 2 027 piksel.
Asl fayl (SVG fayl, asl oʻlchamlari 600 × 475 piksel, fayl hajmi: 104 KB)
| Taʼrif |
English: A diagram showing how two radio stations (blue and red) can be used to find the position at the intersection of two Lines of Position (LOP) of an aircraft. Key is below. |
||
| Sanasi | 12 yanvar 2008 (upload date) | ||
| Manba | self-made, Inkscape 0.45 | ||
| Muallif | Inductiveload | ||
| Ruxsat (Bu faylning takror foydalanilishi) |
|
| TN | True North |
| TH | True Heading |
| TB1 | True Bearing To Station 1 (NDB1) |
| TB2 | True Bearing To Station 2 (NDB1) |
| RB1 | Relative Bearing To Station 1 |
| RB2 | Relative Bearing To Station 2 |
| LOP1 | Line of Position between plane and Station 1 |
| LOP2 | Line of Position between plane and Station 2 |
