Fayl:Pipe root weld with HAZ.jpg
Bu prevyuning hajmi: 359 × 599 piksel. Boshqa oʻlchamlari: 1 380 × 2 304 piksel.
Asl fayl (1 380 × 2 304 piksel, fayl hajmi: 363 KB, MIME tipi: image/jpeg)
Qisqa izoh
| Taʼrif | Partial weld around a pipe joint with clear heat affected zone. This is ASME SA106 Grade B steel pipe NPS 2.5 SCH 80 with J-grooved prepared ends. An automated TIG orbital welder made half an orbit before aborting. The heat affected zone is clearly visible because of the polished ends, even though it is generally innocuous in this material. (SA106 Grade B) Photo by Yannick Trottier, 2006. |
| Sanasi | 2 fevral 2006 (original upload date) |
| Manba | Oʻzimning ishim |
| Muallif | Ytrottier |
Temper Colors
A method of checking temperature is by the temper colors: A given temperature will leave a distinct color corresponding to that temperature on a freshly filed surface. (It should be noted that the presence of alloying elements in the steel affects the colors formed, and some of the higher alloy steels have no temper colors.) This temperature range is very evident in the picture above, at the outside edge of the temper color you can see the transition of all the colors and corresponding temperatures.
Temperature C And Color
204.4 Faint Straw
226 Straw
246.1 Deep Straw
282 Bronze
Peacock
590 Full Blue
640 Light Blue
