Fayl:Npn bjt cross section.svg
Size of this PNG preview of this SVG file: 476 × 212 piksel. Boshqa oʻlchamlari: 2 560 × 1 140 piksel.
Asl fayl (SVG fayl, asl oʻlchamlari 476 × 212 piksel, fayl hajmi: 993 bayt)
Qisqa izoh
| Taʼrif |
English: Simplified cross section of a planar npn Bipolar junction transistor showing the emitter, base and collector contacts and the respective regions with the silicon doping type.
Replacement SVG version of File:Npn BJT cross section.PNG |
| Sanasi | |
| Manba | Oʻzimning ishim |
| Muallif | Matthewbeckler |
Litsenziyalash
|
I, the copyright holder of this work, release this work into the public domain. This applies worldwide. In some countries this may not be legally possible; if so: I grant anyone the right to use this work for any purpose, without any conditions, unless such conditions are required by law. |
